PB2 Series
LED Backlit Panel
Representative model: HYA-PB2-2X2-40W
UL and DLC listed backlit panel with five lumen outputs and five color temperatures selectable on a single model, in 1x4, 2x2 and 2x4 sizes.
ULDLCDamp location
- Wattage
- 5 selectable lumen/wattage tiers
- Lumen output
- 130 lm/W efficiency
- Color temperature
- 3000K / 3500K / 4000K / 5000K / 6500K
- Input voltage
- 120–277V
- CRI
- ≥80
- Ingress protection
- IP20 (indoor)
- Dimming
- 0–10V
- Rated life
- L70 > 50,000 hours
Features
- Surface or suspended mounting kits available
- 110° beam angle for uniform ceiling brightness
- DLC IDs P2U165MP, S-HRQP59, S-FL8HZW
- Quick lumen/CCT selection switch
Options & accessories
- XX: Sensor base
- MS: Motion sensor
- EM: Emergency backup
Recommended applications
Ordering guide
| Model | Size | Watt | Output |
|---|---|---|---|
| HYA-PB2-1X4-TWCCT | 1'x4' | Tunable | 130 lm/W |
| HYA-PB2-2X2-TWCCT | 2'x2' | Tunable | 130 lm/W |
| HYA-PB2-2X4-TWCCT | 2'x4' | Tunable | 130 lm/W |
Data taken from the AVILUX manufacturer specification sheet. Download the PDF above for dimensions, package information and sensor option tables.
