DSL Series
LED Disk Light
Representative model: HY-DSL-R6-15W-3CCT
Low-profile 4" and 6" disk light with three selectable CCTs, ETL and Energy Star listed for retrofit and new construction ceilings.
- Wattage
- 10W (4") / 15W (6")
- Lumen output
- By size
- Color temperature
- 3000K / 4000K / 5000K selectable
- Input voltage
- AC 120V 60Hz
- CRI
- 80+
- Ingress protection
- IP20 (indoor)
- Dimming
- Dimmable
- Rated life
- L70 > 50,000 hours
Features
- 120° beam angle
- Slim profile for tight plenum depths
- CCT switch on the fixture body
- Fast retrofit with included mounting hardware
Options & accessories
- J-box or existing can mounting
Recommended applications
Ordering guide
| Model | Size | Watt | Output |
|---|---|---|---|
| HY-DSL-R4-10W-3CCT | 4" | 10W | Selectable |
| HY-DSL-R6-15W-3CCT | 6" | 15W | Selectable |
Data taken from the AVILUX manufacturer specification sheet. Download the PDF above for dimensions, package information and sensor option tables.
