USDL Series
Ultra Slim LED Downlight
Representative model: HY-USDL-R4-9W-5CCT
Ultra slim recessed downlight in 4", 6" and 8" round, ETL and Energy Star listed with five selectable color temperatures.
- Wattage
- 9W / 12W / 18W
- Lumen output
- By size
- Color temperature
- 2700K / 3000K / 3500K / 4000K / 5000K
- Input voltage
- AC 120V (4") · AC 120–277V (6"/8")
- CRI
- 80+
- Ingress protection
- IP20 (indoor)
- Dimming
- Dimmable
- Rated life
- L70 > 50,000 hours
Features
- 110° beam angle
- Ultra slim housing for shallow ceilings
- CCT switch and cutout guide included
- 5-year limited warranty
Options & accessories
- Junction box included
Recommended applications
Ordering guide
| Model | Size | Watt | Output |
|---|---|---|---|
| HY-USDL-R4-9W-5CCT | 4" round | 9W | Selectable |
| HY-USDL-R6-12W-5CCT | 6" round | 12W | Selectable |
| HY-USDL-R8-18W-5CCT | 8" round | 18W | Selectable |
Data taken from the AVILUX manufacturer specification sheet. Download the PDF above for dimensions, package information and sensor option tables.
