SMD Series
Surface Mount Downlight
Representative model: HY-SMD-R5-10W-3CCT
Surface mount downlight in 5", 7", 9" and 12" with three selectable CCTs, ETL and Energy Star listed for commercial or residential ceilings.
- Wattage
- 10W / 15W / 18W / 24W
- Lumen output
- 650 / 1,050 / 1,250 / 1,800 lm
- Color temperature
- 3000K / 4000K / 5000K selectable
- Input voltage
- 120V 60Hz AC
- CRI
- >80
- Ingress protection
- IP20 (indoor)
- Dimming
- Dimmable
- Rated life
- L70 > 50,000 hours
Features
- 120° beam angle
- No recessed can required
- CCT selection switch on the housing
- Wiring guide and mounting hardware included
Options & accessories
- Multiple aperture sizes
Recommended applications
Ordering guide
| Model | Size | Watt | Output |
|---|---|---|---|
| HY-SMD-R5-10W-3CCT | 5" | 10W | 650 lm |
| HY-SMD-R7-15W-3CCT | 7" | 15W | 1,050 lm |
| HY-SMD-R9-18W-3CCT | 9" | 18W | 1,250 lm |
| HY-SMD-R12-24W-3CCT | 12" | 24W | 1,800 lm |
Data taken from the AVILUX manufacturer specification sheet. Download the PDF above for dimensions, package information and sensor option tables.
